Sealed Micro Switch G9
3 wire micro switch
3 wire micro switch
china micro switch 12v
3 wire micro switch 2
12 volt waterproof micro switch
hermetically sealed micro switch
hermetically sealed micro switch 3
sealed limit switch g9
sealed micro switch
waterproof micro switch 12v
waterproof micro switch
waterproof momentary micro switch

Sealed Micro Switch G9

  • Designed for water and dust-tight (IP67)

  • Small compact size

  • Long life and high reliability

  • Variety of levers and terminals

  • Widely used in auto control, appliance, and industry control

Quote Datasheet

Specifications of Sealed Micro Switch G9

Place of OriginGuangdong, China (Mainland)
Brand NameUnionwell
Model NumberG9 Series
Operation Force150gf/200gf/300gf
Terminal TypeSolder/PCB/Quick Connect/Lead Wires
Lever TypeNo Lever/Hinge/Simulated Roller/Roller
Circuit CodeSPDT/SPST-NO/SPST-NC
CertificationsENEC, UL/cUL, CQC
OEM/ODMAvailable
RatingP10.1A,125/250V  48VDC
Gold Plated Contact Optional
05UL: 5A 125/250VAC
ENEC: 6A 125/250VAC 1E4; 3A 125/250VAC 30VDC 5E4 μ25T120
Operating FrequencyElectrical10~30 cycles/minute
Mechanical120 cycles/minute
Contact Resistance(Initiative)100mΩ Max (without  wire type)
Insulation Resistance (at 500VDC)100mΩ Min
Dielectric strengthAC, 1,000RMS(50-60Hz)
Operating Temperature-25°C~+120°C
Operating Humidity85% RH Max
Life ExpectancyElectrical10,000-10,000 cycles (depending on specific model selection)
Mechanical500,000 cycles


Products

Product Drawing of Sealed Micro Switch G9

micro switch snap action
micro switch smd
micro switch roller type
micro switch precision limit switch
micro switch plunger type
micro switch pin plunger

Sealed Micro Switch G9 Related Applications

Home Appliances and Micro Switches
Home Appliances
