With much smaller dimensions compared to that of normal switches, Unionwell G6 Series mini micro switches are featured with several innovations in construction design-- the adoption of thermoplastic atuating button and case, stainless spring, copper alloy blade, and optional silver or gold crosspoint contacts. The rating current load can vary from 0.1 A up to 12A. It is obviously the best choice for applications in kitchen appliances, automobile, and also valve control.
| Place of Origin | Guangdong, China (Mainland) | |
| Brand Name | Micro Switch Manufacturer Unionwell | |
| Model Number | G6 Series | |
| Operation Force | 50gf/100gf/150gf/250gf/350gf | |
| Terminal Type | Solder/PCB/Quick Connect | |
| Lever Type | No Lever/Hinge/Simulated Roller/Roller | |
| Circuit Code | SPDT/SPST-NO/SPST-NC | |
| Certifications | ENEC, UL/cUL, CQC | |
| OEM/ODM | Available | |
| Rating | P1/P11/P12 | ENEC: 0.1A,125/250V 48VDC 5EA UL: 0.1A,125/250V 48VDC Gold Plated Contact Optional |
| 05/051/052 | ENEC: 5A,125/250VAC UL: 5A, 1/8HP 125/250VAC | |
| 10/101 | ENEC: 10(2)A,125/250VAC μ 25T125 UL: 10.1A, 1/4HP 125/250VAC Note: Only with ''OF''over ''250gf'' | |
| 12 | ENEC: 12(6) A,125/250VAC μ 40T125 UL: 12A, 125/250VAC Note: Only with 350gf OF | |
| Operating Frequency | Electrical | 10-30 cycles/minute |
| Mechanical | 120 cycles/minute | |
| Contact Resistance(Initiative ) | 100mΩ Max (without wire type) | |
| Insulation Resistance (at 500VDC) | 100mΩ Min | |
| Dielectric strength | AC, 1,000RMS(50-60HZ) | |
| Operating Temperature | -25°C~+125°C | |
| Storage Humidity | 85% RH Max | |
| Life Expectancy | Electrical | 10,000-50,000 cycles (depending on specific model selection) |
| Mechanical | 1,000,000 cycles | |
