Refrigerator Micro Switch G91P1
micro limit switch dimensions
micro limit switch dimensions
micro switch 10a 250vac
refrigerator micro switch g91p1
micro limit switch wiring
refrigerator micro switch

Refrigerator Micro Switch G91P1

  • Small dimensions and compact structure

  • High durability and reliability

  • Multiple options for levers and terminals

Contact Us

Specifications of Refrigerator Micro Switch G91P1

Place of Origin Guangdong, China (Mainland)
Brand Name Unionwell
Model Refrigerator Micro Switch G91P1
Operation Force 100gf/150gf/250gf/300gf
Terminal Type Solder/PCB/Quick Connect
Lever Type No Lever/Pin Plunger/Cambered Surface/Straight/Simulated Roller/Roller
Circuit Code SPDT/SPST-NO/SPST-NC
Certifications ENEC, UL/cUL, CQC
OEM/ODM Available
Rating P1 0.1A,125/250V  48VDC
Gold Plated Contact Optional
05 ENEC: 5A 125/250VAC; 5A 1/8HP, 125/250VAC
10 ENEC: 10 (1.5A) 125/250VAC;UL:10A 1/4HP 125/250VAC
Operating Frequency Electrical 10~30 cycles/minute
Mechanical 120 cycles/minute
Contact Resistance(Initiative) 100mΩ Max
Insulation Resistance (at 500VDC) 100mΩ Min
Dielectric strength AC, 1,000RMS (50-60Hz)
Operating Temperature -40°C~+125°C or -40°C~+85°C
Operating Humidity 85% RH Max
Life Expectancy Electrical 10,000-100,000 cycles (depending on specific model selection)
Mechanical 500,000 cycles


Products

Product Drawing of Refrigerator Micro Switch G9

micro switch 10a
micro switch 10a 250vac
refrigerator micro switch
micro switch 10a 2
refrigerator micro switch 2
micro switch 10a 250vac 2

Refrigerator Micro Switch G9 Related Applications
